Manufacturing of micron-scale thin film and flexible circuits and electroformed components used in advanced medical, defense, and industrial devices.

Your Partner in Micron-scale Process Development and Production

Metrigraphics is the world’s leading manufacturer of micron-scale thin film circuits and electrofromed components. We've been providing expert guidance and production services to the U.S. government and industry leaders in every field imaginable for over 50 years.



We are operating in a state-of-the art facilty in Lowell, MA. The facility serves as our complete thin film, electroforming, photolithography, and metallization labs.



In December 2018, Metrigraphics was acquired by Cirtec Medical, a strategic outsourcing partner for complex medical devices. This acquisition fits with Cirtec's focus on active implantables and aligns well with their strategy of expanding capabilities serving minimally invasive interventional therapeutic products. Together, we will continue to expand our innovative design and manufacturing services to help solve our customers' most complex medical device challenges.

Markets

We Serve More Markets Than Anyone Else at This Scale. Metrigraphics is unmatched when it comes to the scope of application and industries served at this scale of technology. In each market, we design and mass-produce micron-scale components that combine ultra-miniature feature size, tight tolerances and high reliability even in harsh environments



Medical Devices · Bio Medical & Pharma · Computer Peripherals · Motion Control · Space · Defense and EW · Instrumentation & Test · Optical Communications · Electronic Components

Metrigraphics Markets
Metrigraphics Markets
Metrigraphics Markets

Capabilities

When it comes to design assistance, prototyping, process development, and mass production of micron-scale cicrcuits and components that combine ultra-miniature feature size, tight tolerances, and high reliability, we're the team innovators turn to. We're also specialists in apply the circuits to flexible polyimide substrates for next generation electrical and bio sensor and wireless devices.



Whether it’s developing nozzle plates for the next generation of high-end, large-format printers, creating millions of sensors for large medical OEMs, or working with the military on high-performance signal transmission applications, Metrigraphics is a proven resource for ultra-miniature component development and high-volume manufacturing.



Our 40,000-square-foot facility includes:

Laboratory, office and production space · 11 class 1000 clean rooms · Three class 100 clean rooms · Seven sputtering systems · Three ion-beam milling systems · Three Suss mask aligners · Separate production and development areas and equipment



Our Clean Room Assembly includes

Substrate cleaners · Photo-resist coaters · Exhaust hoods · Microscopes · Gages · Equipment for visual and microscopic inspection



With 11 available Class 1000 clean rooms, we manufacture a broad range of complex precision components and products and provide wafer/substrate processing. Metrigraphics technicians are accustomed to working with very small, delicate substrates and components during clean room manufacturing processes.

Quality

We differentiate ourselves from our competitors further with impeccable levels of quality and customer satisfaction. As a full service vendor, we’re capable of handling one prototype to tens of thousands of devices per week.



Metrigraphics has committed personnel with an average length of employment of almost 20 years. We’re continually exploring new materials and processes to better serve the changing demands of the marketplace. As such we’re ISO 9001-2008 Certified, ITARS Registered and RoHs Compliant.

Metrigraphics Quality
Metrigraphics Quality
Metrigraphics Quality

Quality

We differentiate ourselves from our competitors further with impeccable levels of quality and customer satisfaction. As a full service vendor, we’re capable of handling one prototype to tens of thousands of devices per week.



Metrigraphics has committed personnel with an average length of employment of almost 20 years. We’re continually exploring new materials and processes to better serve the changing demands of the marketplace. As such we’re ISO 9001-2015 Certified, ITARS Registered and RoHs Compliant.
